SPX Flow CM30P7-1 12V/24V Magnetically Driven Circulation Pump 26 l/min 6.9 GPM

Price

€201.00

Excluding VAT

Heavy Duty Magnetically Driven, Seal-Less Circulation Pumps with Brushed motors for continuous use. Compact and powerful, ideal for circulation duties such as:

- Circulation of water/antifreeze in heating system for cars, boats, recreation vehicles, etc.;

- Circulation for cooling fresh water in vehicles;

- All-round pumps wherever self-priming is not essential.



Johnson pump CM-series is the best in combination with the Webasto or Eberspacher water heaters as a Quality Circulation Pump



FEATURES

  • Limited 2 Year Warranty

  • The CM-series pumps are normal-priming centrifugal pumps and should be mounted in a manner that ensures that they are always flooded or else be primed before being switched on.

  • The pumps should not be used for soiled water containing hard particles.

  • CAUTION! Do not pump gasoline, solvents, thinners, highly concentrated or organic acids. If corrosive fluids must be handled, pump life will be prolonged if flushed with water after each use or after each work day.



Dry running

Max. 30 minutes

Material Specifications

Pump Body

PPA, Thermoplastic

Impeller

PPA, Thermoplastic

Shaft

Stainless Steel

Motor

12/24V DC enclosed (as per IP67) permanent magnet, ball bearing mounted motor, designed for continuous operation

Liquid

Water/glycol mixture; max. 60% glycol, fresh water

Voltage

Technical Details

Pump body

PPA thermoplastic

Impeller

PPS thermoplastic

O-ring

EPDM

Shaft

Stainless steel

Magnet housing

PSU

Motor

12/24V DC enclosed (as per IP67) permanent magnet, ball bearing mounted motor, designed for continuous operation

Liquid

water/glycol mixture; max. 60% glycol, fresh and salt water

Liquid temp.

Min -40°C Max +100°C

Hose connection

Ø 16 mm (5/8") or 20 mm (3/4") hose. Note! CM30P7-1 with Ø 16 mm (5/8") available on request

Codes

Description

SKU

EAN

CM30P7-1, 12V

10-24504-03

7330717000622

CM30P7-1, 24V

10-24504-04

7330717000639

Dimensions

Dimensions and weight

CM30P7-1

Length

177 mm - 6.97"

Width

68 mm - 2.68"

Height

85 mm - 3.35"

Weight

0.6 kg - 1.3 lbs
